Tire Pressure Monitoring Systems (TPMS) are essential components in modern vehicles, ensuring that your tires are properly inflated and alerting you when tire pressure falls below a safe level.
Over time, TPMS sensors can wear out or fail, requiring replacement. This article will guide you through everything you need to know about TPMS sensors, the cost of replacement, and how to change them yourself if you're up for the task.
What is a TPMS Sensor?
A TPMS sensor is a small electronic device located inside your tire, usually mounted on the valve stem. Its primary function is to monitor the air pressure inside the tire and transmit this data to the vehicle's onboard computer. If the pressure drops below a certain threshold, the system triggers a warning light on the dashboard, alerting you to check your tires.
When Do TPMS Sensors Need Replacement?
TPMS sensors typically last between 5 to 10 years or approximately 100,000 miles. They may need replacement for several reasons:
-
Battery Failure: TPMS sensors have built-in batteries that are not replaceable. Once the battery dies, the entire sensor must be replaced.
-
Physical Damage: Impact from potholes, road debris, or tire changes can damage the sensor.
-
Corrosion: Over time, exposure to the elements can cause corrosion, especially in climates with harsh winters.
-
Sensor Malfunction: Like any electronic component, TPMS sensors can malfunction due to internal defects.
Cost of Replacing TPMS Sensors
The cost of replacing a TPMS sensor can vary based on several factors, including the type of vehicle, the brand of the sensor, and whether you choose to do it yourself or have it done professionally.
1. Sensor Cost:
-
OEM Sensors: Original Equipment Manufacturer (OEM) sensors are made by the vehicle manufacturer and are generally more expensive, ranging from $50 to $150 per sensor.
-
Aftermarket Sensors: Aftermarket sensors are made by third-party companies and can be a more affordable option, usually costing between $25 and $75 per sensor.
2. Labor Cost:
If you opt to have a professional replace the sensors, labor costs will be added. These costs vary based on location and the shop’s rates but typically range from $50 to $100 per sensor.
3. Programming Cost:
After installation, TPMS sensors need to be programmed to communicate with your vehicle. Some shops may charge an additional fee for this service, typically between $100 and $200 per vehicle. Little did you know that with the Carista OBD reader and diagnostic app you can register your new IDs quicker and easier. Scroll to learn more.
Related: What is TPMS Registration?
Total Cost:
-
Professional Replacement: Expect to pay between $70 and $250 per sensor, including parts and labor.
-
DIY Replacement: If you choose to replace the sensors yourself, the cost will be significantly lower, primarily just the cost of the sensors themselves.
How to Replace TPMS Sensors: A DIY Guide
If you’re comfortable working on your vehicle, you can replace TPMS sensors yourself. Here’s a step-by-step guide to help you through the process:
Tools and Materials Needed:
-
New TPMS sensors
-
Valve core removal tool
-
Tire removal tools (jack, lug wrench, tire iron)
-
Torque wrench
-
Air compressor or access to a tire inflation service
Step-by-Step Procedure:
1. Safety First:
-
Park your vehicle on a flat surface and engage the parking brake.
-
Wear safety gloves and eye protection.
2. Remove the Tire:
-
Use a lug wrench to loosen the lug nuts on the wheel you’ll be working on.
-
Lift the vehicle using a jack and remove the tire.
3. Remove the Old TPMS Sensor:
-
Deflate the tire by removing the valve core using a valve core removal tool.
-
Break the bead of the tire (this can be done using a tire machine or manually).
-
Carefully push the tire away from the wheel’s rim to access the TPMS sensor.
-
Unscrew the sensor from the valve stem and remove it.
4. Install the New TPMS Sensor:
-
Install the new sensor onto the valve stem and secure it with the provided nut, typically torqued to about 4-7 Nm (check the sensor’s instructions for specifics).
-
Ensure the sensor is correctly positioned and not obstructing the tire.
5. Reinstall the Tire:
-
Re-seat the tire bead on the rim and inflate the tire to the manufacturer’s recommended pressure.
-
Reinstall the tire onto the vehicle and tighten the lug nuts in a star pattern to ensure even tightening.
6. Program the New TPMS Sensor:
-
If required, use a TPMS programming tool to sync the new sensor with your vehicle’s onboard computer. Follow the tool’s instructions or refer to your vehicle’s manual for specific programming procedures:
7. Test the System:
-
Drive the vehicle for a short distance to ensure the new sensors are working properly and that the warning light on the dashboard is off.
Final Thoughts
Replacing TPMS sensors is an important maintenance task that ensures your vehicle remains safe and efficient on the road. While professional replacement is always an option, doing it yourself can save you money and give you a sense of accomplishment. By following the steps outlined in this guide, you’ll be able to replace TPMS sensors with confidence and ensure that your vehicle’s tire pressure monitoring system is functioning correctly.
